CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

Place of Origin : Jiangsu, China (Mainland)

Brand Name : Jkongmotor

Model Number : JK86HS

Certification : CE, ROHS,ISO9001

Price : US $16 - 49 / Pieces

MOQ : 3-10pcs

Packaging Details : with export carton . big quantity with pallet

Delivery Time : For samples , 7-15 days / For batch , 15-25days

Payment Terms : T/T , paypal , Western Union, L/C

Supply Ability : 30000pcs / month

Phase : 2

Step Angle(degrees) : 1.8°

Holding Torque : 3.4N.m - 13N.m

Current / Phase : 2.8A - 6.0A

Body color : black & silver

leads : 4 / 8

MOQ : 10pcs

Contact Now

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

High Performance 86mm Hybrid Stepper Motor 2 Phase Nema 34 Low Vibration cnc kit 4 axis nema 34

Feartures & Benifits:

  • NEMA34 frame size
  • High step accuracy and resolution
  • Low vibration and noise
  • Can be customized for winding current, shaft options and cables and connectors.
  • CE certified and ROHS compliant

Genaral Specification of stepper motor nema 34:

Step Accuracy ------------------------------ ±5%
Resistance Accuracy ----------------------- ±10%
Inductance Accuracy ---------------------- ±20%
Temperature Rise -------------------------- 80°C MAX.
Ambient Temperature Range ------------- -20°C~ +50°C
Storage Temperature Range ------------- -30°C~ +60°C
Insulation Resistance ---------------------- 100M Ω MIN. 500V DC
Dielectric Strength ------------------------- 500V AC 1min
Radial Play --------------------------------- 0.02mm MAX. (450g Load)
End Play ------------------------------------ 0.08mm MAX. (450g Load)
Max. radial force --------------------------- 220N
Max. axial force ---------------------------- 60N

Electical Specifications of nema34 stepper motor:

Model No.

Step Angle

Motor Length

Current

/Phase

Resistance

/Phase

Inductance

/Phase

Holding Torque

Lead

wires

Detent Torque

Rotor Inertia

Motor

Weight

( °)

(L)mm

A

Ω

mH

N.m

No.

Kg.cm

g.cm

Kg

JK86H66-5904

1.8

66

5.9

0.28

1.7

3.4

4

0.8

1000

1.7

JK86H66-2808

1.8

66

2.8

1.4

3.9

3.4

8

0.8

1000

1.7

JK86H78-5504

1.8

78

5.5

0.46

4

4.6

4

1.2

1400

2.3

JK86H78-4208

1.8

78

4.24

0.75

3.4

4.6

8

1.2

1400

2.3

JK86H97-4008

1.8

97

4

0.98

4.1

6.8

8

1.6

1900

3

JK86H97-5008

1.8

97

5

0.65

2.4

6.8

8

1.6

1900

3

JK86H97-2708

1.8

97

2.7

1.9

8.6

6.8

8

1.6

1900

3

JK86H115-6004

1.8

115

6

0.6

6.5

8.7

4

2.4

2700

3.8

JK86H115-4208

1.8

115

4.2

0.9

6

8.7

8

2.4

2700

3.8

JK86H126-4008

1.8

126

4

1.3

5.8

9.3

8

3.0

3200

4.5

JK86H126-5008

1.8

126

5

0.85

3.4

9.3

8

3.0

3200

4.5

JK86H126-2708

1.8

126

2.7

2.5

12.5

9.3

8

3.0

3200

4.5

JK86H155-6204

1.8

153

6.2

0.75

9

12

4

3.6

4000

5.4

JK86H155-4208

1.8

153

4.2

1.25

8

12

8

3.6

4000

5.4

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

Customized shaft:

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.

CNC stepper motor NEMA 34 86*86mm 4.5N.m 8.5N.m 12.0N.m Diameter 12.7/14/15.875mm for medical equipment.
